| Basic Information | ||
| Supported CPU | Ryzen 9000/8000/ 7000 Series Processors for Socket AM5 | |
| Chipset | AMD X870 | |
| Form Factor | ATX 304.8mmx243.84mm | |
| Memory | ||
| Number of Memory Slots | 4x UDIMM | |
| Maximum Memory | 256GB | |
| Supported Memory | upport DDR5 8400+(OC)/ 8200+(OC)/ 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8400+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 4800+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPO Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only* |
|
| Graphics | ||
| Graphics | 1x HDMI Support HDMI 2.1 FRL, maximum resolution of 8K 60Hz 2x Type-C DisplayPort USB4 port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K 60Hz |
|
| Expansion Slots | ||
| Expansion Slots | 3x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E1 slot • Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor) |
|
| Storage | ||
| Supported Storage | 4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280 devices M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2 , supports 2280/2260 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices * The M2_2 slot will be unavailable when using Ryzen™ 8500/ 8300 Series processors. ** USB 40Gbps Type-C ports on the back panel and M2_2 slot share PCIe 5.0 x4 bandwidth. Both run at PCIe 5.0 x2 when a device is installed in the M2_2 slot. You can switch M2_2 to PCIe 5.0 x4 in the BIOS, but this will disable the USB 40Gbps Type-C ports |
|
| Network | ||
| LAN | Realtek 8126-CG 5G LAN | |
| Wireless | Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4, MLO, 4KQAM |
|
| Audio | ||
| Audio | 1x Front Audio (JAUD) | |
| BIOS | ||
| BIOS | PCIe 5.0 x4 in the BIOS, but this will disable the USB 40Gbps Type-C ports | |
| Ports & Connectors | ||
| HDMI | 1x HDMI | |
| USB Ports | USB Type-C 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 3x USB 5Gbps Type A (Rear) 4x USB 5Gbps Type A (Front) 2x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 20Gbps Type C (Front) 2x USB 40Gbps Type C (Rear) |
|
| Display Port | 2x Type-C DisplayPort | |
| RAID | Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices | |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 6x System Fan 1x EZ Conn-header (JAF_2) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports |
|
| Others | ||
| Special feature | 4x EZ Debug LED 1x EZ Digit Debug LED |
|
| Warranty | ||
| Warranty | 3 Years | |
For gamers, creators, and PC enthusiasts, the MSI MAG X870 TOMAHAWK WIFI AM5 DDR5 Motherboard is designed to provide strong performance and dependability. This ATX motherboard, which supports AMD Ryzen 9000 and 8000 series CPUs on the AM5 socket and has the newest AMD X870 chipset, is designed for efficiency, speed, and stability. It supports DDR5 memory, which allows for better performance and more bandwidth for productivity, gaming, and multitasking. With PCIe 5.0 slots for high-speed NVMe SSDs and next-generation graphics cards, the MAG X870 TOMAHAWK ensures smooth performance even under taxing workloads. Superior cooling and system stability under high loads are provided by its sturdy extended heatsink design, M.2 Shield Frozr, and improved power delivery. Users may enjoy lightning-fast and low-latency networking for streaming and gaming thanks to the integrated WiFi 7 and 2.5G LAN. Numerous M.2 ports for fast storage and USB 4.0 and USB 3.2 Gen 2x2 are just a few of its many connectivity options. This motherboard's reinforced PCIe slots, quality components, and MSI's military-class durability promise long-lasting performance. The MAG X870 TOMAHAWK WIFI is a great option for creating a gaming or professional system that is geared for the future since it combines a stylish appearance with sophisticated MSI software features and subtly RGB lighting.The MSI MAG X870 TOMAHAWK WIFI AM5 DDR5 Motherboard comes with 3 Year warranty.
