| Basic Information | ||
| Supported CPU | AMD Ryzen 5000 & 3000 Series Processors | |
| Chipset | AMD B550 |
|
| Form Factor | Micro-ATX Form Factor 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm) |
|
| Memory | ||
| Number of Memory Slots | 4x DDR4 memory slots | |
| Channel Supported | ||
| Maximum Memory | 128GB | |
| Supported Memory | Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE 1DPC 1R max speed 4400 MHZ 1DPC 2R max speed 3733 MHZ 2DPC 1R max speed 3866 MHZ 2DPC 2R max speed 3466 MHZ Supports non-ECC UDIMM memory Supports ECC UDIMM memory Supports un-buffered memory |
|
| Graphics | ||
| Graphics | 1x VGA port, supports resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz 1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz |
|
| Max Shared Memory | 16GB | |
| Expansion Slots | ||
| Expansion Slots | 1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) 2x PCIe 3.0 x1 slots 2x M.2 slots (Key M) M2_1 slot (from AMD Processor) Supports PCIe 4.0/ 3.0 x4 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices M2_2 slot (from AMD B550 chipset) Supports PCIe 3.0x4 Supports 2242/ 2260/ 2280 storage devices |
|
| Storage | ||
| Supported Storage | AMD B550 Chipset 4x SATA 6Gb/s ports 2x M.2 slots (Key M) M2_1 slot (from AMD Processor) Supports PCIe 4.0/ 3.0 x4 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices M2_2 slot (from AMD B550 chipset) Supports PCIe 3.0x4 Supports 2242/ 2260/ 2280 storage devices |
|
| Network | ||
| LAN | 1x Realtek 8111HN Gigabit LAN controller |
|
| Wireless | ||
| Audio | ||
| Audio | Realtek ALC892 Codec 7.1-Channel High Definition Audio |
|
| BIOS | ||
| BIOS | ||
| Ports & Connectors | ||
| HDMI | 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz |
|
| USB Ports | 3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector) 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 1x USB 3.2 Gen 1 5Gbps Type-C port 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) |
|
| DVI-D (s) | ||
| Display Port | 1x DisplayPort supports a maximum resolution of 4096x2160 @60Hz |
|
| Audio | Realtek ALC892 Codec 7.1-Channel High Definition Audio |
|
| RAID | ||
| TPM (Trusted Platform Module ) | 1 x TPM module connector | |
| Internal I/O Ports | 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 4x SATA 6Gb/s connectors 2x M.2 slots (M-Key) 1x USB 3.2 Gen 1 5Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 3x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Serial port connector 1x Chassis Intrusion connector 2x 4-pin RGB LED connectors 2x 3-pin RAINBOW LED connectors 1x Clear CMOS jumper |
|
| Others | ||
| Bundled Software | ||
| Wireless Communication module | ||
| Special feature | ||
| Warranty | ||
| Warranty | 3 years | |
The MSI B550M PRO-VDH AMD AM4 DDR4 Micro-ATX Motherboard is a dependable and cost-effective option for those seeking a combination of performance and reliability in small packages. It runs on the AMD B550 chipset and supports Ryzen 3000, 4000, and 5000 series processors, giving it a versatile platform for gaming, productivity, and everyday usage. DDR4 memory supports speeds of up to 4400+ MHz (OC), ensuring fast and responsive performance. The board incorporates PCIe 4.0 for next-generation graphics cards and NVMe SSDs, which provide increased bandwidth and data transfer speeds. Storage possibilities are expanded with several M.2 slots and SATA connectors, while audio and networking features ensure smooth connectivity and great sound. Its Core Boost technology and advanced thermal solutions offer efficient power supply and stability even under severe loads. Its Micro-ATX form factor makes it perfect for smaller cases while maintaining critical functions. Overall, the MSI B550M PRO-VDH provides reliable performance, durability, and current features, making it a great choice for budget-conscious PC builders .The MSI B550M Pro-VDH AM5 DDR4 mATX Motherboard comes with 3 years warranty.
