| Basic Information | ||
| Supported CPU | AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors | |
| Chipset | AMD B850 | |
| Form Factor | ATX Form Factor 304.8 x 243.84mm |
|
| Memory | ||
| Number of Memory Slots | 4 x UDIMM | |
| Maximum Memory | 256GB | |
| Supported Memory | max. 256GB, DDR5 Support DDR5 8400 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen 9000 Series Processors max. overclocking frequency: 1DPC 1R Max speed up to 8400+ MT/s 1DPC 2R Max speed up to 6400+ MT/s 2DPC 1R Max speed up to 6400+ MT/s 2DPC 2R Max speed up to 4800+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only |
|
| Graphics | ||
| Graphics | 1 x HDMI port Support HDMITM 2.1 with FRL port, supporting a maximum resolution of 8K 60Hz |
|
| Expansion Slots | ||
| Expansion Slots | Supports PCIe 5.0 x16 (For Ryzen 9000/ 7000 Series processors) Supports PCIe 4.0 x8 (For Ryzen 8700/ 8600/ 8400 Series processors) Supports PCIe 4.0 x4 (For Ryzen 8500/ 8300 Series processor) 4 x M.2 |
|
| Storage | ||
| Supported Storage | Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports M.2_1 Source (From CPU) supports up to PCIe 5.0 x4, supports 22110/2280 devices M.2_2 Source (From CPU) supports up to PCIe 5.0 x4, supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2, supports 2280/2260 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices 4x SATA 6G M.2_1 slot Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors) Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors) M.2_2 slot Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors) Supports up to PCIe 4.0 x4 (For Ryzen 8700/ 8600 / 8400 Series processors) Supports up to PCIe 4.0 x2 (For Ryzen 8500/ 8300 Series processors) |
|
| Network | ||
| LAN | 1x Realtek 8126 5G LAN | |
| Wireless | Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4, MLO, 4KQAM |
|
| Audio | ||
| Audio | 1 x Audio jacks | |
| Ports & Connectors | ||
| HDMI | 1x HDMI | |
| USB Ports | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 1x USB 5Gbps Type A (Rear) 4x USB 5Gbps Type A (Front) 2x USB 10Gbps Type A (Rear) 3x USB 10Gbps Type C (Rear) 1x USB 20Gbps Type C (Front) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports |
|
| Display Port | 1x DisplayPort | |
| Audio | 1 x Audio jacks 1x Front Audio (JAUD) |
|
| RAID | Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices RAID 10 for M.2 NVMe storage devices is only supported by AMD Ryzen 9000/7000 series CPU |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 6x System Fan 1x EZ Conn-header (JAF_2) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) |
|
| Others | ||
| Special feature | 4x EZ Debug LED 1x EZ Digit Debug LED 1x EZ Memory Detection LED |
|
| Warranty | ||
| Warranty | 3 Years | |
The MSI MPG B850 EDGE TI WIFI AM5 ATX Motherboard is designed for high-performance gaming and productivity, featuring the AMD B850 chipset with support for Ryzen 9000, 8000, and 7000 Series processors on the AM5 socket. It supports DDR5 memory for faster speeds, higher bandwidth, and better overclocking capabilities. The ATX form factor provides multiple expansion slots, including PCIe 5.0 for next-gen graphics cards and M.2 slots with heatsinks for ultra-fast NVMe SSD storage. For connectivity, it includes WiFi 6E, 2.5G LAN, and USB 4.0/Type-C ports for reliable networking and high-speed data transfers. Enhanced power delivery and efficient cooling solutions ensure stability during demanding workloads, making it suitable for gamers and creators alike. The Titanium design combined with customizable RGB lighting through MSI Mystic Light adds a premium aesthetic to any build, making the MSI MPG B850 EDGE TI WIFI an excellent choice for powerful and stylish PC setups. The MSI MPG B850 EDGE TI WIFI AM5 ATX Motherboard comes with 3 years warranty.
