| Basic Information | ||
| Supported CPU | Intel Core Ultra Processors (Series 2), LGA 1851 | |
| Chipset | 4x DDR5, Max 256GB 9200 - 6400 (OC) MT/s | |
| Form Factor | ATX (243.84mmx304.8mm) | |
| Memory | ||
| Number of Memory Slots | 4 |
|
| Maximum Memory | 256GB |
|
| Supported Memory | Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 9200+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s • 2DPC 1R Max speed up to 4800+ MT/s • 2DPC 2R Max speed up to 4800+ MT/s |
|
| Graphics | ||
| Graphics | 1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* 1x Type-C DisplayPort Thunderbolt™ 4 port, supporting DisplayPort 1.4 over USB Type-C®, with a maximum resolution of 4K 120Hz / 8K 60Hz* |
|
| Expansion Slots | ||
| Expansion Slots | 3x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset) |
|
| Storage | ||
| Supported Storage | 4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
|
| Network | ||
| LAN | Realtek 8126 5Gbps LAN | |
| Wireless | Intel® Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth® 5.4**, MLO, 4KQAM |
|
| Audio | ||
| Audio | 1x Front Audio (JAUD) |
|
| Ports & Connectors | ||
| HDMI | 1x HDMI | |
| USB Ports | USB Type-C 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 4x USB 5Gbps Type A (Front) 1x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 20Gbps Type C (Front) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports |
|
| Display Port | 1x DisplayPort 1x Type-C DisplayPort Thunderbolt™ 4 port, supporting DisplayPort 1.4 over USB Type-C |
|
| Audio | 1x Front Audio (JAUD) | |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| Internal I/O Ports | 1x Thunderbolt5 card connector(JTBT5, support RTD3) 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 5x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports |
|
| Warranty | ||
| Warranty | 3 Years | |
The MSI PRO Z890-P WIFI DDR5 LGA 1851 ATX Motherboard is a dependable and performance-driven board that supports the newest Intel 14th and 15th Generation Core CPUs using the sophisticated LGA 1851 socket. Built on the Intel Z890 chipset, it provides reliable performance and compatibility for both productivity and gaming. It supports DDR5 memory, which provides increased bandwidth and efficiency for faster data processing and smoother multitasking. The ATX form factor has plenty of expansion options, making it ideal for professional workstations and custom PC systems. With integrated WiFi 7 and 2.5G LAN, it provides fast, stable, and low-latency access for online gaming and demanding workloads. The motherboard also includes several PCIe 5.0 and PCIe 4.0 slots for next-generation graphics cards and high-speed storage devices, enabling future upgradeability. Improved power supply with a premium VRM design enables steady overclocking and system dependability under high loads. It also includes innovative cooling solutions, such as improved heatsinks and fan headers, to ensure performance efficiency. Multiple USB ports, including USB 3.2 Gen 2x2 Type-C, enable rapid data transfer and versatile connectivity for current peripherals. The MSI PRO Z890-P WIFI DDR5 ATX Motherboard is a good choice for professionals, content creators, and gamers looking for a future-ready platform for strong PC builds. It balances performance, durability, and connection well. The MSI PRO Z890-P WIFI DDR5 LGA 1851 ATX Motherboard comes with 3 Year warranty.
