| Basic Information | ||
| Supported CPU | Intel Core Ultra Processors (Series 2), LGA1851 socket | |
| Chipset | Intel H810 | |
| Form Factor | Micro-ATX | |
| Memory | ||
| Number of Memory Slots | 2 x UDIMM | |
| Channel Supported | Supports Dual-Controller Dual-Channel mode | |
| Maximum Memory | 128GB | |
| Supported Memory | Memory Support DDR5 6400 - 4800 (JEDEC) MT/s | |
| Graphics | ||
| Graphics | 1x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz |
|
| Expansion Slots | ||
| Expansion Slots | 1x PCI-E x16 slot 2x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset) |
|
| Storage | ||
| Supported Storage | 1x M.2 M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G |
|
| Network | ||
| LAN | Realtek 8125 2.5Gbps LAN | |
| Audio | ||
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
|
| Ports & Connectors | ||
| HDMI | 1x HDMI Support HDMI™ 2.1, maximum resolution of 4K 60Hz |
|
| USB Ports | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 10Gbps Type C (Front) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports |
|
| Display Port | 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* |
|
| Audio | Realtek® ALC897 Codec 7.1-Channel High Definition Audio |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports |
|
| Warranty | ||
| Warranty | 3 years | |
The MSI PRO H810M-B DDR5 LGA 1851 mATX Motherboard is a dependable and compact solution designed for productivity and everyday PC building. It is designed with the Intel H810 chipset and supports the most recent Intel 14th and 13th Generation processors on the LGA 1851 socket, ensuring efficient performance and long-term compatibility. This motherboard supports DDR5 memory, which provides higher bandwidth, faster speeds, and better multitasking capabilities than previous standards. Its micro-ATX form facto makes it an ideal choice for compact and mid-sized cases, while also providing necessary expansion with PCIe slots for graphics cards or extra devices. The PRO H810M-B has M.2 slots and SATA ports for storage, letting you can use both fast NVMe SSDs and classic hard drives. Connectivity is handled using a set of USB 3.2 and USB 2.0 ports, HDMI and DisplayPort for integrated graphics output, and reliable networking connectivity for everyday use. MSI's technologies, such as Core Boost and Memory Boost, ensure optimum CPU power delivery and consistent RAM performance, while built-in Audio Boost improves sound quality for clear, precise audio. Designed for durability and reliability, the MSI PRO H810M-B DDR5 LGA 1851 mATX Motherboard is a good solution for those looking for a low-cost yet strong foundation for office systems, home PCs, or light productivity setups. The MSI PRO H810M-B DDR5 LGA 1851 mATX Motherboard comes with 3 Year warranty.
