| Basic Information | ||
| Supported CPU | LGA1700 socket: Support for 14th, 13th, and 12th Generation Intel Core, Pentium Gold, and Celeron Processors. | |
| Chipset | Intel H610 Express Chipset | |
| Form Factor | Micro ATX Form Factor (23.0cm x 21.5cm) | |
| Memory | ||
| Number of Memory Slots | 2 x DDR5 DIMM sockets | |
| Channel Supported | Dual-channel memory architecture | |
| Maximum Memory | Up to 128 GB (Maximum 64 GB single DIMM capacity) | |
| Supported Memory | DDR5 5600 / 5200 / 4800 / 4400 MT/s memory modules | |
| Graphics | ||
| Graphics | Integrated Graphics Processor (Intel HD Graphics support): • 1 x HDMI port (Max 4096x2160 @ 60 Hz, HDMI 2.1 / HDCP 2.3) • 1 x DisplayPort (Max 4096x2304 @ 60 Hz, DP 1.2 / HDCP 2.3) | |
| Max Shared Memory | Dependent on the installed Intel CPU capability (Shared system memory) | |
| Expansion Slots | ||
| Expansion Slots | • CPU: 1 x PCI Express x16 slot (Supports PCIe 4.0, running at x16) • Chipset: 1 x PCI Express x1 slot (Supports PCIe 3.0, running at x1) | |
| Storage | ||
| Supported Storage | • 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 3.0 x4/x2 SSD support) • 2 x SATA 6Gb/s connectors | |
| Network | ||
| LAN | Realtek GbE LAN chip (1 Gbps / 100 Mbps / 10 Mbps) | |
| Audio | ||
| Audio | Realtek Audio CODEC, High Definition Audio (2/4/5.1/7.1-channel), support for S/PDIF Out | |
| BIOS | ||
| BIOS | 1 x 128 Mbit flash; Licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
| Ports & Connectors | ||
| HDMI | 1 x HDMI 2.1 port | |
| USB Ports | Chipset: • 4 x USB 3.2 Gen 1 ports (2 on back panel, 2 via internal header) • 6 x USB 2.0/1.1 ports (4 on back panel, 2 via internal header) | |
| Display Port | 1 x DisplayPort 1.2 | |
| RAID | Not natively supported by H610 Chipset for SATA/NVMe | |
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI V2 module only) | |
| Internal I/O Ports | 1x 24-pin main power, 1x 8-pin 12V power, 1x CPU fan header, 1x system fan header, 1x M.2 Socket 3, 2x SATA 6Gb/s, 1x front panel header, 1x front panel audio header, 1x USB 3.2 Gen 1 header, 1x USB 2.0/1.1 header, 1x TPM header, 1x Clear CMOS jumper | |
| Others | ||
| Bundled Software | GIGABYTE APP Center (Norton Internet Security, LAN bandwidth management software) | |
| Special feature | Smart Fan 6 (multiple temperature sensors, hybrid fan headers with FAN STOP), Audio Noise Guard with high-quality audio capacitors, Anti-Sulfur design, Solid pin power connectors | |
| Warranty | ||
| Warranty | 3 Years | |
The GIGABYTE H610M K DDR5 is a high-performance Micro ATX motherboard built for Intel’s 12th, 13th, and 14th Gen Core processors with LGA1700 socket support. Featuring next-generation DDR5 memory architecture, it delivers up to 128GB RAM capacity across 2 x DIMM slots with XMP 3.0 support for speeds up to 5600 MT/s, offering 50% more bandwidth than DDR4. The board includes a PCIe 4.0 x16 slot for modern GPUs and an NVMe PCIe 3.0 x4 M.2 slot for rapid boot times and fast data access. Storage options expand with 4 x SATA III ports. Connectivity includes Gigabit Ethernet LAN, HDMI 2.1 (4K@60Hz), DisplayPort 1.2, USB 3.2 Gen 1, and USB 2.0. Cooling is managed via Smart Fan 6 with hybrid headers and temperature sensors. Durability is enhanced with GIGABYTE’s Anti-Sulfur Resistor technology. The motherboard carries a standard 3-year warranty from GIGABYTE. Ideal for budget gaming and productivity builds demanding DDR5 efficiency and PCIe 4.0 speed
